FA1217 High Production Cotton Carding Machine

The FA1217 High Production Cotton Carding Machine is a high-performance cotton carding solution engineered for spinning preparation lines. With a working width of 1280mm and a total carding area of 3.84m², it delivers a 30% increase in carding area and production capacity compared to conventional models. The optimized distribution of front stationary flats, rotary flats, and rear stationary flats ensures exceptional carding capability while maintaining superior sliver quality.

Inquiry Now

Technical Data

Specifications
Working width		1000mm/1280mm
Feeding Method		Consequent Feeding Reverse Feeding（Optional）
Web Layer Count ( g/m)		3.5- 10
Applications		Applicable for cotton、 in length from 22 to 76mm
Sliver delivery speed(m/min) (design)		400m/min
Max. production (kg/h)		200kg/h
Total Draft Ratio		40- 370
Licker-in diameter(mm)		Ф 250
Cylinder diameter(mm)		Ф1288
Cylinder speed(r/min)		305~550
Doffer diarmeter(mm)		Ф706
Doffer speed(/min)		6~120
Revolving flats (working/ total)		38/105
Flat speed(mm/min)		100~400
Auxiliary carding segment	Carding segment under licker-in	2
	Front stationary flats	10
	Rear stationary flats	10
	Web cleaner	PET：F(2)B(2） COTTON:F(3)B(3)
Continuous air suction volume (m3 /h·set)		4500
Static pressure oft outlet (pa)		-800
Compressed air requirement(kg/cm2)		6~7
Air consumption (m3 /h)		0.2
Total installed power(kw)		14kw
Satety cover		Totally enclosed structure
Net weight (kg)		800
Dimension (L x W)(mm)		5500x 2300

Key Advantages:

Excellent Carding Quality – Enhanced carding area and flat distribution significantly improve fiber processing, delivering uniform sliver with minimal nep and waste.

High Yield & Efficiency – Production capacity increased by nearly 30%, reducing investment costs in floor space, labor, and energy consumption.

Flexible Configuration – Multiple configuration options available to match your specific raw materials and textile applications, ensuring adaptability to changing market demands.

Cost-Effective Design – Higher output with lower operating costs provides faster return on investment for spinning mills.
